Exploded Animations: Making the Assembly the Story

Every part, in motion.

An exploded animation separates selected components so the audience can understand what is inside or how parts relate. The movement, detail and labels should support that question. A cinematic separation is not automatically an assembly instruction.

Overview

Parts apart, on purpose.

This is not a particle or fire explosion effect. Nothing is destroyed. The parts move apart in a controlled way, then often return.

Use it when the inside of the product, or the way its parts relate, helps the audience understand it. The shot depends on the 3D asset: the hierarchy has to allow component-level movement, and every part that becomes visible has to hold up at close range.

What does this reveal need to prove?

An exploded shot can do four different jobs. Each needs different movement, source information and review. Agree which one you are making before animation starts. The client technical reviewer below is a role to agree for the project, not a fixed step in every job.

JobAudience questionSuitable movementSource neededWho reviews
Internal feature revealWhat is inside that I cannot see?A partial separation or cutaway that exposes the one feature, then closesGeometry or drawings for every internal part that becomes visibleYour technical reviewer and the marketing owner
Component relationshipHow do these parts fit together?An axial or multi-direction separation with clear spacing and one stable reference partThe assembly structure, part names and the approved relationship between partsYour technical reviewer
Promotional hero momentWhy does this product feel engineered?A short, directed separation and return inside the launch filmThe parts the shot shows, finish references, the channel and the lengthThe marketing owner, with a technical check that nothing implies a wrong mechanism
Procedural assembly explanationIn what order do I put this together?Sequential steps in the real, approved orderAn approved assembly sequence, step by stepYour technical reviewer

A true assembly instruction needs an approved real sequence. A marketing reveal can take liberties with order and spacing, but it must not show a mechanism that is wrong. For the procedural job, plan an instructional sequence instead.

The lead example: Squire, with Curious Agency

Curious Agency briefed XO3D for Squire, a British lock maker. The case study records two exploded view animations, for the Inigma and Boron lock systems, plus a library of hero renders.

It also records that the sequence was worked from Squire engineering data, so that it could serve as a marketing asset and as a technical reference. On that project Alex Mann was Creative Director and Thomas Howcroft was Producer.

The Squire film below is the clearest version of the component-relationship job. The padlock closes, separates along one axis with each part spaced so it can be read, then reassembles. It runs for seven seconds. See the Squire work with Curious Agency for both lock films and the stills.

Check the source before the shot is planned

Most problems with an exploded shot start in the source files. Before the movement is planned, confirm:

  • The source revision. Which CAD or drawing revision the film shows.
  • The parts list. Part names, so the movement, labels and review notes refer to the same parts.
  • The hidden detail. Which internal parts will become visible. Internal geometry cannot be inferred from the outside; if it is missing, it has to be supplied or the shot changes.
  • The approved relationship or order. Who confirms how the parts relate, and whether the order matters.
  • Finish references. Material and colour references for parts seen close up for the first time.
  • The final output. Where the film will run, its shape, and whether it carries labels or sound.

CAD saves modelling time when it is clean and complete. Assemblies are often grouped for manufacture rather than for movement, so the hierarchy may need rework before parts can move one by one. Read how to prepare CAD for CGI, preview the movement in an animatic before the final render, and what a render does and does not prove.

How an artist keeps an explode readable

Jack Robertson, a former XO3D 3D artist, set out his working rules for exploded animation in a written answer in October 2026. He had not worked on the exploded films published on this page, so these are his general rules rather than notes on those projects. His words, edited for clarity:

“I would usually try to move things in groups. If there were a bunch of screws all in one panel, I’d have them animated out together rather than one at a time, so there are fewer individual part motions to set up.”

“Generally there’s one main direction for the exploded parts, with potentially a secondary axis to create a slight arc.

Most parts follow that one direction to keep everything uniform and intentional.

A frantic exploded shot has parts travelling in all different directions with no rhyme or reason, rotation that doesn’t match the direction of travel, and a general sense of procedural generation that doesn’t understand what an artist would be trying to show.”

“An exploded animation would generally be between 4 and 10 seconds, depending on what’s being exploded. Anything shorter may be too quick and jarring. Anything longer may be boring and drawn out unnecessarily.”

On the Flash Motors Infinity X controller, the published XO3D explode with the most parts, he said: “It doesn’t look cluttered because all of the parts move purposefully. They don’t fly out in random directions, they don’t touch or clip one another, and they are angled to the camera to show the details.”

For very large assemblies he keeps a firm grip on the groups, and sometimes uses procedural simulation patterns where animating every part by hand would take far too long. “This usually results in a clean explode control that I can change the values of to suit my needs.”

Black Duux Neo humidifier exploded along one diagonal axis, from the lid at the top to the wooden stand at the bottom, with the internal parts shown translucent, CGI by XO3D
Duux Neo humidifier, exploded still. Every part follows one diagonal axis, the single main direction Jack describes. Supplied by Jack Robertson for this guide. See the Duux Neo project.

Plan the versions with the shot

Labels, clean versions, portrait crops and still diagrams are scoped around where each one will be used. Decide them before the animation is approved, so the camera is planned for them.

  • A horizontal explode spreads wide. In a 9:16 crop the parts can leave the frame, so a narrow version may need its own camera.
  • A labelled version needs space and hold time for each label. Labels in more than one language are separate versions.
  • A still diagram may need its own composition and lighting rather than a frame taken from the film.

Shot length follows how many parts the viewer must read. It can also be made before manufacture, when the CAD and finish references for that revision are approved. For a planning figure on animation cost, use the Labs animation price calculator.

For sibling topics, see 3D product animation and technical animations. For the single-frame version of the technique, see exploded views as stills. To commission one, see exploded view and cutaway animation, or the wider director-led product animation. When you are ready, tell us what your exploded shot needs to show.

Examples

Exploded animation, clip by clip.

Axial explode and return

The Squire padlock, apart and back.

The lock closes, its parts separate along the vertical axis, and it reassembles, in seven seconds. Produced with Curious Agency for Squire.

Multi-direction explode

Plumis Automist, opened out.

The Automist unit's front panel, valve body and housing move apart in several directions, then close again.

Disassembly

Infinity X controller, taken apart.

Fixings, boards and components move out of the Flash Motors Infinity X controller housing.

Front-to-back explode

A pedestal fan, along its axis.

The guard, blades and hub of a pedestal fan slide forward along the motor axis, so each layer reads on its own.

White pedestal fan with its front guard and blades separating along the motor axis

Compilation

Several products, one square cut.

A square compilation of exploded shots from several products, cut for social placements.

First frame of a square compilation of exploded product shots

Detail beat

A held close-up between moves.

A three-second close-up on the Flash Motors logo on the scooter. It does not explode: it is the kind of held detail that sits between moving shots.

Advantages

Where it earns its place.

  • Shows what the shell hides.

    Where the value sits inside the product, a controlled separation lets the audience see it.

  • A clear moment in a launch film.

    A short separation and return can mark the point where the film explains the product.

  • Material for other outputs.

    The same 3D build can supply stills and channel versions. Each is scoped and composed for where it will run.

Trade-offs

What to plan for.

  • Hierarchy setup is essential.

    The 3D asset must have a component hierarchy that allows each part to move. Late hierarchy changes mean rework.

  • Every part must model well.

    An explode shows each part at close range. Under-modelled components show up immediately.

  • Not every product benefits.

    Products without meaningful internal complexity get little from exploded animation.

  • Timing is craft.

    Too fast and the parts cannot be read; too slow and the shot drags. Timing is set in blocking and checked before the final render.

Process

An illustrative shot workflow.

These steps describe how one exploded shot is typically built. The stages and review points for your project are agreed in the scope.

  1. STAGE 1

    Brief and hierarchy plan.

    Which parts separate, which stay assembled, in what order and at what pace.

  2. STAGE 2

    Modelling and hierarchy.

    The 3D asset is structured for component-level movement, and every part that will be seen is modelled to close-view quality.

  3. STAGE 3

    Animation blocking.

    The explode is blocked in a playblast to check pacing and geometry.

  4. STAGE 4

    Cameras and framing.

    Cameras follow the separation and show the key components at the moments that matter.

  5. STAGE 5

    Rendering and finish.

    Full render with motion blur and depth of field. A compositing pass ties it together.

  6. STAGE 6

    Agreed versions.

    The versions agreed in the scope, such as a clean cut, a labelled cut or a portrait crop, are made from the approved animation. A narrow crop may need its own camera.

Who this is for

Built for teams shipping the launch.

Engineering-led product marketing teams. Industrial, medical, robotics and consumer electronics brands.

Teams explaining a product before release, and agencies developing a technical launch, can use an exploded sequence to clarify component relationships.

Written by

XO3D Studio

Director-led product CGI studio

FAQ

Common questions, answered.

Is an exploded animation the same as an explosion effect?

No. An exploded animation separates a product's parts to show what is inside or how they fit, and usually brings them back together. Effect libraries and AI templates make a different thing: fire, debris and particles.

What should the reveal show?

The one thing the audience needs to understand: an internal feature, how two parts relate, or a moment in a launch film. Showing every part can bury that point, so choose the level of detail first.

Is our source information good enough?

CAD is the usual source, but it may need hierarchy work so the parts can move separately. Any internal part that becomes visible needs real geometry or drawings; it cannot be inferred from the outside. The files are assessed before the shot is committed.

Is a promotional explode the same as an assembly instruction?

No. A promotional separation can move parts in the order that reads best, as long as it does not imply a wrong mechanism. A procedural film follows the approved real sequence and is checked by your technical reviewer. Decide which one you need in the brief.

When is a simpler view better?

When the interior or the assembly does not help the story. A clear exterior shot, a turntable or a single exploded still may answer the question with less work.

How long is a typical exploded shot?

It depends on how many parts the viewer must read and where the film will run. The clips on this page run from about 2 to 15 seconds. Sequential or labelled versions usually need longer.

Can we produce exploded animation before manufacture?

Yes, when the CAD and finish references for that revision are approved. The film shows the revision you supply, so a later design change means updating the model.

Working on a project?

Tell us about it.

Thomas or Alex replies personally, usually within one working day.

Planning your project

Let the construction tell the story.

An exploded animation separates a product into visible components. It can reveal an internal feature, explain the relationship between parts or create a controlled moment in a launch film.

The technique is strongest when the assembly itself helps the audience understand the product.

Tell us about your brief
Exploded view of Squire lock components
Squire lock animation produced with Curious Agency. Explore the project

Decide what the reveal proves.

Start with the detail that matters. Is the viewer meant to understand a mechanism, a material layer or the relationship between two components?

Showing every part can obscure that point. Select the level of detail that supports the explanation.

Choose the movement.

An axial separation suits a product organised around a shared direction. A sequential reveal introduces parts in a chosen order. A cutaway can preserve more context when a full separation would be confusing.

The component hierarchy and model need to support the movement. Internals that will become visible must be represented from adequate source information.

Keep the product readable.

Use a stable reference, deliberate spacing and enough time for the viewer to connect the parts. Labels should point to specific information.

Macro surfaces need the same attention as the exterior. A reveal loses credibility when newly exposed components look less resolved than the housing.

Review the meaning.

A cinematic reveal is not necessarily a real assembly instruction. Confirm whether the sequence is explanatory, promotional or procedural, and review it accordingly.

A launch shot can also supply stills, but a useful technical diagram may require a different view and composition.

Bring the detail worth revealing.

Tell us what the audience needs to understand beneath the surface.
