Types of Storyboards: Formats and When to Use Each

Different storyboards. Different jobs.

Storyboards come in several formats. Thumbnail sketches for fast ideation. Detailed boards for shot-by-shot lock. Animatics for pacing verification. 3D previz for camera work. This guide covers when to use each.

Written by XO3D Studio, a director-led product CGI studio in Stevenage, directing product CGI since 2017. Updated .

Overview

A storyboard is a sequence of frames that plans a film before production. Each frame shows one shot: what the viewer sees, from where, and in what order.

What is the purpose of storyboarding?

The purpose of storyboarding is to let everyone agree the shot choice and the story before expensive production starts. Changing a drawing is quick; changing a lit, rendered shot is not.

Not every film needs every format. Short loops can use a simplified animatic, simple hero shots often skip previz, and long-form projects usually use every format. The ladder below shows what each format locks.

Storyboard fidelity ladder: written beat sheet locks the story beats, thumbnails lock the shot ideas, the detailed board locks framing and action, the colour board locks mood and light, the animatic or greycard locks timing and movement, and 3D previz locks camera moves and space
Storyboard fidelity ladder: each format locks one more decision.

On this page: storyboard types at a glance, one AUAR shot from board to final, which board you approve, how to read a board, which formats your film needs and mistakes at board stage.

What's covered

The main varieties, in detail.

Thumbnail

Fast, rough, iterative.

Rough pencil or digital sketches. Meant to be thrown away and redrawn. Fastest way to explore ideas.

Detailed

Every shot, drawn properly.

Full storyboard with framing, camera angle, action and product or character position. Signed off before production. Shown: the annotated AUAR MicroFactory board.

Close-up of the AUAR MicroFactory animation storyboard printout, with hero and detail shots annotated

Animatic

Storyboard in time.

An animated storyboard: the shots timed and moving, with reference music or voiceover and rough timing. A generic animatic can be timed 2D boards; XO3D builds its animatic in simplified 3D geometry, and its artists call this stage the greycard. Locks pacing before final rendering. Shown: AUAR grey card pass A05.

AUAR grey card pass A05, robot and rack in the studio for camera and composition sign-off

3D previz

Rough 3D blocked shots.

Simple 3D shots with placeholder geometry showing camera moves. Bridges storyboard and full production.

Colour storyboard

Storyboard with mood colour.

Storyboards painted or coloured to convey mood, lighting and atmosphere per shot.

Beat sheet

Written pacing outline.

Text-only version of the storyboard, listing beats, timing and key moments. Fastest to iterate on.

Advantages

Why brands commission it.

  • Right fidelity per stage.

    Quick iteration early, high fidelity later. Fidelity escalates as decisions lock.

  • Multiple boards catch different issues.

    Thumbnail catches ideation weakness. Animatic catches pacing. Previz catches camera. Each format catches different problems.

  • Cross-team alignment.

    Different stakeholders need different fidelity. Executives read animatic, artists work from detailed boards.

  • Reusable during changes.

    Change locks at each fidelity level. Late change means retrofitting up the ladder.

Trade-offs

What to plan for.

  • Time investment per format.

    Each storyboard format adds time. Balance the investment against the risk of skipping.

  • Not every project needs all formats.

    Short loops can use a simplified animatic. Simple hero shots may skip previz. Match format to project complexity.

  • Client-facing formats need explanation.

    Some clients read animatic naturally, others do not. Explain what they are looking at before review.

  • Escalation can trap resources.

    Locked boards can become psychological anchors, hard to change even when they should. Keep some flexibility.

Process

How the work is produced.

  1. STAGE 1

    Thumbnail pass.

    Fast rough sketches exploring shot ideas. Quick to iterate.

  2. STAGE 2

    Beat sheet check.

    Written beats verified against the runtime and target platforms.

  3. STAGE 3

    Detailed board.

    Full detailed storyboard with framing, angle, action. Signed off.

  4. STAGE 4

    Animatic.

    Boards timed to voiceover or reference music. Pacing locked.

  5. STAGE 5

    Previz if needed.

    3D previz for complex camera moves or product-in-scene work.

  6. STAGE 6

    Production.

    Full production runs against the locked storyboard package.

Who this is for

Built for the people who approve the film.

Creative Directors and Brand Directors who sign off a product film. Product Marketing Directors who need the launch story to land.

Agency producers managing an external animation partner, and anyone asked to approve a storyboard without having drawn one.

For the wider topic, see 3D product animation.

Storyboard types at a glance

Other sites group these formats differently: traditional and digital, written, or 2D and 3D. The table puts those names next to what each format is for.

FormatWhat it isWho reads itDecision it settlesWhat it cannot showAlso called
ThumbnailsSmall, rough sketches of possible shotsThe director and artistsWhich shot ideas are worth developingFraming detail, timing, finishRough boards, traditional boards
Written beat sheetA text list of beats, timing and key momentsClient, director, producerThe story and its orderAny image at allWritten storyboard, beat outline
Detailed boardEvery shot drawn with framing, angle and action, by hand or digitallyClient and artistsShot selection and orderTiming, lighting, materialsTraditional or digital storyboard, 2D board
Colour boardBoards coloured to show mood and light per shotClient and art directionMood and atmosphereExact materials, movementColour script
AnimaticThe boards or rough shots timed and movingClient and stakeholdersPacing, timing and product movementFinal materials and lightingAnimated storyboard, greycard at XO3D
3D previz or greycardSimple 3D geometry with real camerasDirector, artists and clientCamera moves, scale and spaceFinal look3D storyboard, previs
Product-film boardA detailed board led by the product’s features and their orderBrand and product teamsWhich features appear, and whenHow the finish will read under lightShot list with frames

One AUAR shot, from board to final

The AUAR MicroFactory film shows the ladder on a real project. The storyboard went up on the studio wall first, set out from the supplied model, movement references and brand guidance.

AUAR MicroFactory animation storyboard mounted on the studio wall for pre-production shot planning
The AUAR storyboard on the studio wall. It plans the whole film; it is not a drawing of shot A05 below.

The grey card pass came next: the shot built in plain grey geometry for camera and composition sign-off. Materials and lighting were added only once that was agreed.

AUAR grey card pass A05, robot and rack in the studio for camera and composition sign-off
Grey card pass for camera and composition sign-off, shot A05.
AUAR final rendered composition A05, robot and rack with lighting and materials applied
Final, shot A05: the same composition with lighting and materials applied.

The same order held for wider shots. Grey pass C01 used containers in the yard as a scale reference for the final C02 shot.

AUAR grey card pass C01, containers in the yard as a scale reference for the final C02 shot
Grey card pass C01, containers as scale reference.
AUAR final rendered composition C02, MicroFactory containers travelling through the yard
Final, shot C02: the MicroFactory containers in the yard.
Grey to final, a six-second transition loop from the AUAR film. Press play.

Explore the AUAR process, including every grey-to-final comparison.

Three more projects show what boards settle:

  • Petalite. The Petalite case study says storyboards and a simple animatic mapped the narrative, key messages and camera moments before animation began, and aligned stakeholders early.
  • Bluestork. The Bluestork storyboard covered left- and right-handed versions in black and white. When two variants were dropped, the concept no longer held, so the film was rebuilt around the remaining mouse.
  • Nanuskate. On the Nanuskate skate ramp, greycard passes locked the assembly order before the final film.

Which board will you be asked to approve?

Before a final render, a buyer usually sees three artefacts. Each settles a different question, and each has things that are deliberately not there yet.

The storyboard. It settles shot selection, the order of reveals, which product features are shown and the overall direction of the film. Exact lighting, material quality and camera smoothness are not present at this stage. The storyboard is a structural document.

The animatic. The animatic is the main pre-production approval for a product film. It settles camera choreography, timing, edit rhythm and the order of product movement. It uses rough geometry and no lighting on purpose, so judging render quality here is judging the wrong thing. At XO3D this is the greycard stage, signed off before material previews begin.

The material test. It settles whether the materials match the physical product’s surface under light: the finish, texture and colour. Camera angle and composition are not its subject.

Watch the animatic at full speed more than once. Are the reveals well timed? Is any shot too short to read? Does the mechanism move in the correct operational order? Our guide on how to review each stage covers the final render review too, and what a 3D animatic is explains the animatic in full.

How to read a board if you are not a storyboard artist

You do not need to draw to review a board well. Read it as a plan, not a picture.

Look for:

  • Shot selection. Is every shot doing a job, and is anything missing?
  • Order. Does the sequence of reveals make sense to someone seeing the product for the first time?
  • Product features. Which features appear, and when? Is the most important one given enough time?
  • The story. Does the whole board serve the film’s purpose: a launch, a technical explanation or an investor pitch?

Ignore, for now:

  • Lighting, material quality and how smooth the camera feels. None of these exist at board stage, and they are reviewed later.
  • Drawing style. A rough sketch can carry a good shot.

What a board cannot tell you is how the product will look under light, or exactly how long each moment lasts. Those questions belong to the material test and the animatic. For the vocabulary of the shots themselves, see our guide to camera shots.

Which formats does your film need?

FilmUsual formatsCan often skip
Short loopBeat sheet and detailed board, with a simplified animatic3D previz
Hero product filmBeat sheet, detailed board and animatic3D previz, unless the camera moves are complex
Long-form filmEvery format on the ladderNothing, usually

The product CGI timeline shows where these stages sit in a full project. Placeholder audio in the animatic is covered in sound design for product films.

Mistakes at board stage

Approving finish at board stage. A board cannot show materials or light, so a comment on finish here has nothing to act on. Note it for the material test instead.

Letting a board become an anchor. Once a board is approved, it can feel fixed even when the brief has moved. Bluestork is the example: when two of the mouse variants were dropped, the original concept no longer worked, and the right call was a new animation with new camera angles rather than forcing the old board.

Boarding in the wrong aspect ratio. A film planned only in landscape can lose its action in a vertical crop.

On AUAR’s film, XO3D planned extra render canvas where crops would work and a custom camera where vertical framing needed it. Nanuskate’s launch included vertical 9:16 social cuts alongside the wide film.

Tell the studio every format you need before boarding starts; the greycard review then checks the action in each frame shape.

Next steps

A storyboard plans the film. To commission the film itself, see our 3D product animation studio or director-led product CGI films.

To brief one, use the CGI brief template and name the outputs, the review schedule and who signs off each board. The animatic guide covers animated storyboards in more depth.

For finished product films, see the Sony WF-C710 segments for ImageNova and the G-Lab keyboard launch film.

Written by

XO3D Studio

Director-led product CGI studio

FAQ

Common questions, answered.

What does storyboard mean?

A storyboard is a sequence of drawn or rendered frames that plans a film shot by shot before production. When those frames are timed and set moving, the result is an animatic, an animated storyboard.

What is the purpose of storyboarding?

Storyboarding settles the shot selection, the order of reveals, which product features appear and the overall story before production starts. Lighting, materials and camera smoothness are not part of that review.

What is the difference between a storyboard and an animatic?

A storyboard is a set of still frames. An animatic is a timed, moving version of the storyboard, built at XO3D in simplified 3D geometry without final materials or lighting. It is the main pre-production approval for a product film.

What does a storyboard for a product film actually show?

The shots in order, which product features appear and when, and the overall story the film tells. It is a structural document, so exact lighting, material quality and camera smoothness are not on it.

Which storyboard do I approve, and what is out of scope at that stage?

You review the storyboard for story, shot order and which features appear, then the animatic for timing, camera moves and product movement. Judge materials and lighting later, at the material test and final render stages.

How many review rounds are there?

XO3D includes three review rounds on stills projects and four on anything including video, as stated in the proposal. No separate count is published for the board stage.

Do all projects need every storyboard format?

No. Match format to complexity. Short loops can use a simplified animatic, simple product shots often skip previz, and long-form projects usually use all formats.

Which format is best for client review?

Animatic is usually the best format for stakeholder review because it shows pacing. Detailed boards are good for artist handover.

How do 3D previz and animatic differ?

An animatic is an animated storyboard that checks timing, pacing and product movement. XO3D builds it in simplified 3D geometry and its artists call this stage the greycard. 3D previz blocks out complex camera moves and space in rough 3D; it checks spatial and camera decisions rather than timing.

Can we use existing footage as reference in the animatic?

Yes. Rough reference music, voiceover and even reference frames from other projects all help pacing calibration.
